Tekram P6BX-A - Seite 3

Features

Hier nochmal die oben bereits angesprochenen Features im Überblick:

Prozessor

• SLOT 1 support Intel Pentium II / III and Celeron Processors (66/100 MHz FSB)

Suspend to RAM

• Intel 440BX-100

BIOS

• Award PCI BIOS, support ACPI, DMI, Green PC, Plug-and-Play
• Boot from CD-ROM, SCSI, LS-120 , ZIP devices
• Symbios SCSI BIOS
• Anti-virus BIOS to prevent Boot-Virus

System Speicher

• 3´168-pin DIMM Sockets up to 768 MB SDRAM Memory Capacity
• Support 8/16/32/64/128/256 MB Memory Module

On-board I/O Komponenten

• 1xFloppy Port ( Up to 2.88MB )
• 1xParallel Port ( EPP, ECP Port)
• 2xSerial Ports ( 16550 Fast UART Compatible)
• 2x USB Ports
• 1xIrDA TX/RX Header
• 1xPower State Header
• 1xMIDI/game port
• 1xAudio Jacks: Line Out, Line In, and Mic. In

Erweiterte Komponenten

1. Modem Ring-in Remote Power on
2. Wake Up On Lan
3. Keyboard Power On
4. Hardware Monitoring function
5. SB-Link to support Sound Blaster card for early DOS games
6. ESS Solo1 PCI Sound Chip – Support Software Wavetable
7. Suspend on RAM

PCI Bus Master IDE

• 2x UltraDMA/33 IDE Ports Support
• UltraDMA/33: 33MB/Sec.

Erweiterungsslots

• 1×32-bit AGP Slot, 5×32-bit PCI Bus Master Slots, 2×16-bit ISA Slots

ATX Power Anschluss

• 3V, 5V and 12V 20 Pin ATX Power connector

VR Umschalter

• Switching Voltage Regulator to support 1.3V to 3.5V

Bauform

• ATX Size (7.5″ x 12″ or 190mm x 305mm)
